Trusted Mild Steel Pipe Suppliers & Manufacturers for Every Project

Explore our comprehensive range of mild steel pipes crafted with precision and backed by the assurance of quality. As your trusted supplier and manufacturer, we stand committed to delivering excellence for diverse applications.

Unbeatable Quality and Value: Your Preferred Mild Steel Pipe Suppliers

We take pride in being your preferred source for top-quality mild steel pipes. Our commitment to unbeatable quality and value sets us apart as leading suppliers and manufacturers in the industry.

Quality Assurance in Every Mild Steel Pipe - Choose Proven Manufacturers

When it comes to quality assurance, our mild steel pipes stand as a testament to our commitment. Explore our range and experience the difference of choosing proven manufacturers for your construction and industrial needs.

Reliable and Sustainable

At Ramdev Steel India, reliability and sustainability are at the core of our offerings. As your go-to mild steel pipe suppliers, we prioritize delivering products that not only meet but exceed your expectations.

Check Below Mild Steel Pipes, Mild Steel Flanges, Mild Steel Sheet Plate & Mild Steel Fittings

Our range of Mild Steel Galvanized Pipes is available as per drawing and expansion as per required size & length. There are heat treatment, galvanizing, machining, etc.

Mild Steel Pipes Offred by Ramdev Steels India

Material	Size (in mm)	Sch. & Swg.	Specification
Mild Steel (M. S.) & G. I.	15 NB to 150 NB	'A' Class 'B' Class 'C' Class	IS 1239
Mild Steel (M. S.) & G. I.	200 NB to 500 NB	4.85 mm to 12.7 mm Thk.	IS 3589 (Fe 330, Fe 410)

Grades: - IS 1239, IS 3589 (Fe 330, Fe 410)

Length: Standard, double & in cut length also.

Test Certificate: Manufacturer Test Certificate

Laboratory Test Certificate from Govt. Approved Lab.

Under Third Party Inspection.

Specialize:

Square tube, rectangle tube & odd size

Mild Steel Pipes, MS Tubes Supplier IS:1239|IS:3589 in India

Mild Steel Pipes, MS Tubes Dimensions Confirming to IS: 1239 (Part – I) – 2004, Equivalent to BS – 1387 / 1985

Nominal Bore		Outside Diameter		Light (A-Class) Thickness Weight		Medium (B-Class) Thickness Weight		Heavy (C-Class) Thickness Weight
Inch	mm	Inch	mm	mm	kg/mtr	mm	kg/mtr	mm	kg/mtr
1/8?	3 mm	0.406	10.32	1.80	0.361	2.00		2.65	0.493
1/4?	6 mm	0.532	13.49	1.80	0.517	2.35	0.407	2.90	0.769
3/8?	10 mm	0.872	17.10	1.80	0.674	2.35	0.852	2.90	1.02
1/2?	15 mm	0.844	21.43	2.00	0.952	2.65	1.122	3.25	1.45
3/4?	20 mm	1.094	27.20	2.35	1.410	2.65	1.580	3.25	1.90
1?	25 mm	1.312	33.80	2.65	2.010	3.25	2.440	4.05	2.97
1.1/4?	32 mm	1.656	42.90	2.65	2.580	3.25	3.140	4.05	3.84
1.1/2?	40 mm	1.906	48.40	2.90	3.250	3.25	3.610	4.05	4.43
2?	50 mm	2.375	60.30	2.90	4.110	3.65	5.100	4.47	6.17
2.1/2?	65 mm	3.004	76.20	3.25	5.840	3.65	6.610	4.47	7.90
3?	80 mm	3.500	88.90	3.25	6.810	4.05	8.470	4.85	10.1
4?	100 mm	4.500	114.30	3.65	9.890	4.50	12.10	5.40	14.4
5?	125 mm	5.500	139.70	–	–	4.85	16.20	5.40	17.8
6?	150 mm	6.500	165.10	–	–	4.85	19.20	5.40	21.2

Big Diameter Mild Steel Pipes, MS ERW Pipes Confirming to IS 3589, Grade FE330, Grade FE410

Wall Thickness	NominalBore 7? NB 193.7 mm OD	NominalBore 8? NB 219.1 mm OD	NominalBore 10? NB 273 mm OD	NominalBore 12? NB 323.7 mm OD	NominalBore 14? NB 355.6 mm OD	NominalBore 16? NB 406.4 mm OD	NominalBore 18? NB 457mm OD	NominalBore 20? NB 508 mm OD
mm	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr	Kg/mtr
4.85	22.59	25.62	32.07	38.13	–	–	–	–
5.20	24.17	27.43	34.34	40.85	–	–	–	–
5.60	26.00	29.28	36.93	43.93	48.11	–	–
6.00	27.88	31.53	39.50	47.02	51.49	61.00	69.00	–
6.35	29.34	33.28	41.73	49.67	54.43	62.35	70.50	78.50
7.01	32.77	36.76	46.43	55.45	61.82	69.04	–	–
7.94	–	41.00	50.95	61.85	67.98	77.94	87.80	–
8.18	–	42.56	53.42	65.12	–	–	–	–
9.53	–	51.50	60.24	73.75	81.21	93.13	105.00	117.00
12.70	–	–	–	–	107.28	123.30	139.00	155.00

MiId Steel Pipes, Tubes Tolerance as per IS:1239

(a) Thickness
(1)	Butt welded Light tubes	+Not limited – 8 percent
	Medium and Heavy tubes	+ Not Limited – 10 percent
(2)	Seamless Tubes	+Not Limited – 12.5 percent

(b) Weight :
(1)	Single tube (light series)	+10 percent – 8 percent
(2)	Single tube (medium & heavy Series)	+10 percent

Mild Steel Pipes, MS Tubes Product, Stock Range Size: 15mm NB to 150mm NB (1/2” to 6”), 7″ (193.7mm OD to 20″ 508mm OD)

Dimension & Tolerance: Mild Steel Pipes Dimensions – IS: 1239 (Pt I) – 2004, Equivalent to BS – 1387 / 1985

Specifications: IS – 1239 (Part -1) 2004, Equivalent to BS – 1387 / 1985

Surface Finish: Black

Features: High Strength, Corrosion Resistant, High Toughness and Deformability

Length: As per customer’s requirement (Maximum upto 7 meters)

Features: High Strength, Corrosion Resistant, High Toughness and Deformability

What are the Applications of Mild Steel Pipes and Mild Steel Tubes?

Industrial Water Lines, Plant Piping
Agriculture and Irrigation
Galvanized Steel Fencings
Road Barriers
Parking Barriers
Temporary Fencings
Steel Gates & Windows
Road Side Railings
Structural and fabrication work
Water Pipelines
Sewerage Systems
Oil Pipe Lines
Oil Refinery Piping, Crude Oil Piping

Mild Steel Flanges Manufacturer, Supplier in India

Forged Flanges/Plate Flanges

Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size	1/2″ to 48″
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Class / Pressure	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Product		Size
Mild Steel Slip-On Flanges	Mild Steel Threaded Flanges	1/2″ – 48″ Raised Face or Flat Face
Mild Steel Weld Neck Flanges	Mild Steel Socket Weld Flanges
Mild Steel Blind Flanges	Mild Steel Reducing Flanges
Mild Steel Lap Joint Flanges	Mild Steel Plate Flanges

Mild Steel Sheet Plate Manufacturer, Supplier in India - Mild Steel Sheet, Mild Steel Plate, Mild Steel Coil

Mild Steel & Carbon Steel Plates

We provide our clients with a precision engineered range of carbon steel plates and carbon steel sheets that are made from the alloys of steel. The carbon steel plates made from carbon alloy holds the following capacities:

Harder and stronger
Less ductile
More difficult to weld
Low melting point
Temperature resistance in general
Carbon Steel 1015 = S15C / 1045 = S45C

The sheets and plates fabricated from steel alloy possesses the physical properties of density, reactivity, young's modulus, and electrical and thermal conductivity almost same as those of its elements, but the engineering properties are much different. Those properties of steel alloy are:

High tensile strength
High shear strength
Free-Cutting Steel 12L14 = SUM24L / 1215 = SUM23 / 1144 = SUM43
The Following Grades Are Available:
Carbon Steel Plates : ASTM / ASME A 516 / 517 GR. 60 / 70, IS 2062, IS 2002
Mild Steel Plates : ASTM A36
S275JR
IS-2062 GR. A / B, Fe 410WA, Fe 410WB

Range of Mild Steel Sheet, Plate, Strip, Flat & Blank
Sr. No.	Material	Size	Thickness	Specification
1.	Mild Steel	1220 mm x 4880 mm 1500 mm x 6300 mm 2000 mm x 10000mm 2500 mm x 10000mm	1 mm To 150 mm	IS 2062
2.	GI	1220 mm x 2440 mm 1220 mm x 6000 mm 1500 mm x 6300 mm	1 mm To 20 mm	DIN, BS, IS EN Series

Note :

Other Grade :- CRCA, Spring Steel, Silver Steel Etc.

Sheet Finishinng :- HR, CR Etc.

Sheet & Plate in Form of :- Coils, Chequred Plate, Perforated Sheet, Strip, Blank (Circle), Ring (Flange), Flats, Angle, Channel, ‘T’, I Beam, Tray Etc.

Other Services :- Heat Treatment, Anneling, Pickling, Electroplating, Anodising, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.

Test Certificate :- Manufacturer Test Certificate / Laboratory Test Certificate from Govt. Approved Lab. & Under Third Party Inspection with Excise Gate Pass to avail Modvat benefit.

Mild Steel Pipe Fittings Production Range

Grade Specification	Mild Steel: ASTM/ASME A234 WPB / A860 – MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70Low temperature Steel: A420 WPL3 / A420 WPL6
Type	Seamless / Welded / Fabricated
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Range	½”NB to 48″NB in Sch 10s, 40s, 80s, 160s, XXS.
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.

Buttweld Mild Steel Pipe Fittings

Seamless/ Welded 100% Radiography Tested

Products		Size
Mild Steel Elbows – Long Radius	Mild Steel Stub Ends	Sizes 1/2″ – 48″
Mild Steel Elbows – Short Radius	Mild Steel Crosses
Mild Steel Reducing Elbows	Mild Steel Reducing Crosses
Mild Steel 45° Elbows	Mild Steel 180° LR Return Bends
Mild Steel Tees	Mild Steel 180° SR Return Bends
Mild Steel Tees	Mild Steel Pipe Bends / Piggable Bends
Mild Steel Reducers	Mild Steel Couplings
Mild Steel Concentric Reducers	Mild Steel Pipe Nipples
Mild Steel Eccentric Reducers	Mild Steel Forged/Plate Cut Rings
Mild Steel 3D Elbow	Mild Steel End Caps
Mild Steel 5D Elbow	Mild Steel Forged / Plate Circles

High Pressure Forged Mild Steel Pipe Fittings

Threaded and Socket Weld Pipe Fittings

Products		Size
Mild Steel 90° Elbows	Mild Steel Couplings	Sizes 1/8″ – 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Mild Steel 45° Elbows	Mild Steel Reducers
Mild Steel Street Elbows	Mild Steel Inserts
Mild Steel Tees	Mild Steel Caps
Mild Steel Crosses	Mild Steel Unions

Mild Steel Flanges

Forged and Plate Flanges

Grade/Specification	ASTM A105 / A350 LF2, ASME SA105, A694 – F42, F46, F52, F60, F65, F70, A36, A516 Gr. 70, 60 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Size	½” to 36″
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Class / Pressure	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Product		Size
Mild Steel Slip-On Flanges	Mild Steel Threaded Flanges	1/2″ – 36″ Raised Face or Flat Face
Mild Steel Weld Neck Flanges	Mild Steel Socket Weld Flanges
Mild Steel Blind Flanges	Mild Steel Reducing Flanges
Mild Steel Lap Joint Flanges	Mild Steel Plate Flanges
